EB PCG 1013 Support Insulator

Name: EAE Elektroteknik
Start: 2025-05-10T10:00:00+03:00
End: 2025-05-10T17:00:00+03:00
Location: EAE Elektroteknik

Material

Polycarbonate with glass fiber reinforced

Does not emit halogen gas when burned (Halogen free)

Properties

Rated insulation voltage

Order Codes
EB PCG 1013

SUPPORT INSULATOR SHORT CIRCUIT WITHSTAND CURRENT - 1 s.

Enclosure Rated Width	Distance Between Insulators L (mm)	Busbar Cross-Sections (mm)
04	300
05	400
06	500
07	600
08	700

30x10	40x10	50x10	60x10	80x10	100x10	120x10
47 kA	31 kA	36 kA	36 kA	36 kA	36 kA	36 kA
41 kA	27 kA	31 kA	36 kA	36 kA	36 kA	36 kA
36 kA	24 kA	28 kA	34 kA	36 kA	36 kA	36 kA
33 kA	22 kA	25 kA	31 kA	36 kA	36 kA	36 kA
31 kA	20 kA	23 kA	29 kA	33 kA	33 kA	33 kA
